LKAD068D-D 72W 10-42V 1700mA DALI Dimming LED drivers
  • LKAD068D-D 72W 10-42V 1700mA DALI Dimming LED drivers

LKAD068D-D 72W 10-42V 1700mA DALI Dimming LED drivers

  • Product model : LKAD068D-D
  • Input voltage : 200-240Vac
  • Output power(W) : 72W
  • Output voltage : 10-42Vdc
  • Output current(A) : 1100-1700mA
  • Light adjustment : DALI Dimming
  • Size(MM) : 123x79x33mm
Authentication:
Skype
  • Product Detail
  • Send Inquiry
  • Download

LKAD068D-D 72W 10-42V 1700mA DALI Dimming LED drivers

Features

  • 200-240VAC(50/60Hz) Input
  • Isolated,DALI dimming,flicker free
  • Hight efficiency,hight PF,good steady;
  • The copper wire of transformer is Grade F,resist high-temperature 155℃(usually 120℃)
  • independent, ClassⅡconstant current type;
  • short circuit/over load/over current/ over temperature protection;
  • 100% full load burn-in test;
  • degree of protection IP20 (or IP65 for optional)
  • suitable for LED lighting,ceiling light,down light and panel light;
  • 5 years warranty.


More Details

Model LKAD068D
输入             Input AC电压范围/AC Voltage range 200-240V 200-240V
频率/Frequency 50/60hz 50/60hz
谐波/THD ≤45% ≤15%
功率因数/Power factor 0.91/230VAC 0.94/230VAC
输出      Output 额定电压/Rated voltage 40V 40V
空载电压/No-load Voltage 50V 50V
DC电压范围/DC voltage range 30-40V 30-40V
DC电流范围/DC current range 1440-1550mA 880-910mA
电流精度/Current precision ±3% ±3%
额定功率/Rated power 60W 36W
开机延时/Setup Time ≤0.5s/230VAC ≤0.5s/230VAC
使用环境    Environment Requirements 工作温度/湿度要求                    Operating Temp./RH -30~+45℃/20~95%
储存温度,湿度要求                   Storage Temp./RH -40~+80℃/10~95%
安全和电磁兼容 认证编号/Certificate ----
其他 尺寸/Size L123*W79*H33mm
重量/Net weight
