Features
| Model | LKAD026D-A | |||||
| 输入 Input | AC电压范围/AC Voltage range | 200-240V | ||||
| 频率/Frequency | 50/60hz | |||||
| 谐波/THD | ≤10%/230VAC | |||||
| 功率因数/Power factor | 0.98 | |||||
| 输出 Output | 额定电压/Rated voltage | 42V | ||||
| 空载电压/No-load Voltage | 48V | |||||
| DC电压范围/DC voltage range | 20-42V | |||||
| DC电流范围/DC current range | 500mA | |||||
| 电流精度/Current precision | (+/-)5% | |||||
| 额定功率/Rated power | 21W | |||||
| 输入纹波/Output ripple | <200mV | |||||
| 开机延时/Setup Time | ≤0.5s/230VAC | |||||
| 使用环境 Environment Requirements | 工作温度/湿度要求 Operating Temp./RH | -30～+45℃/20～95% | ||||
| 储存温度,湿度要求 Storage Temp./RH | -40～+80℃/10～95% | |||||
| 安全和电磁兼容 | 认证编号/Certificate | IEC61347-2-13 EN6147-2-13 | ||||
| EN55015 | ||||||
| Fcc Part15B | ||||||
| 其他 | 尺寸/Size | 122x44x27mm | ||||
| 重量/Net weight | / | |||||
