| Authentication: |
|
Model |
|
LKAD060P |
|
输入Input |
AC电压范围/AC Voltage range |
90-277V |
|
频率/Frequency |
50/60Hz |
|
|
谐波/THD |
|
|
|
功率因数/Power factor |
0.93/230VAC |
|
|
输出Output |
额定电压/Rated voltage |
42V |
|
空载电压/No-load Voltage |
45 |
|
|
DC电压范围/DC voltage range |
25-42V |
|
|
DC电流范围/DC current range |
1120-1250mA |
|
|
电流精度/Current precision |
(+/-)5% |
|
|
额定功率/Rated power |
50W |
|
|
开机延时/Setup Time |
≤0.5s/230VAC |
|
|
使用环境Environment Requirements |
工作温度/湿度要求Operating Temp./RH |
-30～+45℃/20～95% |
|
储存温度,湿度要求 Storage Temp./RH |
-40～+80℃/10～95% |
|
|
安全和电磁兼容 |
认证标识/Certificate |
UL:E475760 |
|
FCC:EM201500163-1 |
||
|
SAA:SF201501543 |
||
|
CCC:2016011002845332 |
||
|
其他 |
尺寸/Size |
L125+16mm*W52mm*H33mm |
|
重量/Net weight |
|
